ABB CI522A (3BSE018105R1) Analog Input Module

Product Overview

The ABB CI522A (also known by order code 3BSE018105R1) is a highly versatile and configurable 8-channel analog input (AI) module from the renowned S800 I/O family. It serves as a fundamental data acquisition component within ABB's flagship automation systems, including System 800xA and AC 800M programmable controllers.

This module is engineered to interface with a wide array of field sensors, translating critical real-world process measurements—such as temperature, pressure, level, and flow—into precise digital signals for the control system. Its flexibility and high density make it an ideal choice for a vast range of industrial applications where accurate and reliable data collection is paramount.

Key Features & Technical Specifications

• High Channel Density: Eight isolated analog input channels on a single module, maximizing control cabinet space and reducing cost per point.

• Extreme Versatility: Each channel is individually configurable via software to accept a multitude of signal types:

  • Current: 0-20 mA, 4-20 mA (standard process signals)

  • Voltage: 0-10 VDC, ±10 VDC

  • Resistance Temperature Detectors (RTDs): Pt100, Pt200, Pt500, Pt1000, Ni100, Cu10

  • Thermocouples (TCs): Types J, K, R, S, T, N, E, B

• High Accuracy and Resolution: Provides exceptional measurement precision essential for tight control loops and accurate monitoring, ensuring process integrity and product quality.

• Advanced Diagnostics: Features comprehensive self-diagnostics and channel-level monitoring to detect wire breaks, short circuits, and out-of-range signals, enabling predictive maintenance and reducing downtime.

• Hot Swappable: Designed for hot-swapping in redundant power supply configurations, allowing for module replacement without shutting down the process, which is critical for high-availability systems.

• S800 I/O Integration: Modules are mounted on a S800 I/O Fieldbus (e.g., FI820F, FI830F) and communicate via Profibus DP with the AC 800M controller.

Typical Technical Data:

• Manufacturer: ABB

• Part Number: CI522A

• Ordering Code: 3BSE018105R1

• Module Type: Analog Input (AI)

• Number of Channels: 8

• Isolation: Channel-to-channel and channel-to-bus

• System Compatibility: System 800xA, AC 800M, S800 I/O

Primary Applications

The CI522A module is deployed across numerous process and manufacturing industries for critical data acquisition:

• Chemical & Pharmaceutical: Monitoring reactor temperatures (via RTD/TC), pressure vessel levels, and precise flow rates.

• Oil & Gas: Measuring wellhead pressures, pipeline flow, and tank farm inventory levels.

• Power Generation: Monitoring steam and water temperatures, bearing vibrations, and fuel flow.

• Pulp & Paper: Controlling consistency measurements, dryer section temperatures, and chemical additive flows.

• Water & Wastewater: Measuring pH levels, chlorine residual, pump discharge pressure, and reservoir levels.

Compatibility & System Integration

The CI522A is a core component of ABB's modern automation architecture:

• DCS/PLC: Integrates seamlessly with System 800xA and AC 800M controllers.

• I/O System: Part of the S800 I/O family. It requires a compatible S800 I/O Fieldbus (e.g., FI820F, FI830F) for mounting and communication.

• Engineering Tool: Configured and commissioned using ABB's Control Builder software suite, where engineers can define the signal type, scaling, and alarm limits for each channel.

Why Choose the ABB CI522A?

• Unmatched Flexibility: The ability to handle almost any type of analog sensor on a single module simplifies spare part management and system design.

• Proven Reliability: Built to ABB's high-quality standards for operation in harsh industrial environments, ensuring long-term stability and reduced lifecycle costs.

• Future-Proof Investment: As part of the scalable System 800xA, it protects your automation investment and ensures long-term component availability.

• Reduced Engineering Time: Standardized configuration within a unified system architecture speeds up commissioning and maintenance.

FAQs

Q: Is the CI522A module hot-swappable?
A: Yes, the CI522A can be hot-swapped in systems configured with redundant power supplies, allowing for maintenance without a process shutdown.

Q: Can I mix different signal types on one module?
A: Absolutely. Each of the 8 channels can be independently configured for a different signal type (e.g., Channel 1 for 4-20mA, Channel 2 for Pt100 RTD).

Q: Do you offer refurbished or new units?
A: We provide both new, genuine ABB units and professionally refurbished modules. All refurbished units are rigorously tested and come with a warranty to ensure they meet original performance specifications.

Q: What is the difference between 3BSE018105R1 and CI522A?
A: CI522A is the common product name or type designation. 3BSE018105R1 is the specific order code or article number used for purchasing. They refer to the exact same product.
