ABB 5SHX1445H0001 High-Power IGBT Module

The ABB 5SHX1445H0001 is a high-current, medium-voltage IGBT (Insulated Gate Bipolar Transistor) module engineered for demanding power conversion applications. Designed with robustness and efficiency in mind, it serves as a critical component in industrial drive systems, ensuring reliable control of high-power motors and machinery.

1. Product Overview

The ABB 5SHX1445H0001 is a dual IGBT module that functions as a high-power electronic switch. It is designed to efficiently convert and control electrical power in advanced medium-voltage converters, enabling precise speed and torque regulation for large industrial motors. Its high current rating makes it suitable for applications requiring significant power throughput.

• Product Type: Dual IGBT Module with Anti-Parallel Diodes

• Core Function: Power switching and conversion in Voltage Source Inverters (VSIs) for industrial drives.

• Key Application: A key component in medium-voltage drive systems, potentially used in series like the ACS1000 or similar.

• Technology: Advanced IGBT technology, optimized for a balance of low switching losses and high short-circuit ruggedness.

2. Technical Specifications

The following table outlines the key electrical and mechanical parameters of the 5SHX1445H0001.

3. Product Features

The 5SHX1445H0001 incorporates design features that make it a reliable and high-performance choice for industrial environments.

• High Current Capability: With an 800A rating, this module is built to handle very high power levels, making it ideal for driving large motors in the megawatt range.

• Robust Press-Pack Design: The press-pack housing eliminates bond wires, providing superior thermal cycling performance, low thermal impedance, and a non-catastrophic failure mode, enhancing system safety and longevity.

• Optimized for Efficiency: Engineered for low conduction and switching losses, contributing to higher overall system efficiency and reduced operating costs.

• Proven Reliability: Designed and manufactured to withstand the electrical and thermal stresses of heavy industrial use, ensuring maximum uptime.

4. Applications

This IGBT module is deployed in industries where high power, reliability, and precise control are critical.

• Industrial AC Drives: A core power component in medium-voltage AC drives for sectors like metals, mining, and cement.

• High-Power Motor Control: Used for controlling large pumps, fans, compressors, and conveyor systems in critical process industries.

• Energy & Infrastructure: Suitable for use in custom power conversion systems, large UPS, and renewable energy applications.

• Marine Propulsion: Employed in the drive systems of large vessels.
