Product Summary: The Pinnacle of Power Switching

The ABB 5SHY3545L0020 represents the peak of high-voltage, high-current semiconductor technology within the renowned ABB HiPak series. This press-pack IGBT module combines an impressive 4500V blocking voltage with a massive 1200A nominal current rating, making it one of the most powerful modules available for the most critical and demanding applications on the grid and in heavy industry.

Engineered for extreme reliability, its press-pack design is essential for systems where modules are stacked in series to achieve megawatt-level power conversion. It is the component of choice for engineers building infrastructure where failure is not an option.

Why Choose the 5SHY3545L0020?

• Unmatched Power Density: 4500V and 1200A in a single module enables compact and efficient design of very high-power systems.

• Superior Press-Pack Technology: Facilitates double-sided cooling for maximum heat dissipation and offers a "fail-short" mode, enhancing system-level protection and availability.

• Designed for Maximum Uptime: Exceptional thermal cycling performance ensures long service life in 24/7 operation, reducing the total cost of ownership.

• Optimized for Series Stacking: Low parasitic inductance and robust mechanical construction are ideal for multi-level converter topologies used in HVDC.

Technical Specifications: ABB 5SHY3545L0020

Critical Applications

The 5SHY3545L0020 is deployed at the heart of the world's most powerful electronic systems:

• HVDC Transmission Links: A key component in both Voltage-Sourced Converter (VSC) and Current-Sourced Converter (CSC) designs for efficient, long-distance power transmission.

• FACTS (Flexible AC Transmission Systems): Essential for STATCOMs, SSSCs, and UPFCs that regulate voltage, stabilize grids, and increase power transfer capacity.

• Megawatt-Class Industrial Drives: Drives for massive motors in mining (e.g., ore conveyors, hoists), metal processing (rolling mills), and marine propulsion.

• Large-Scale Renewable Energy Plants: Power conversion in big offshore wind farms and solar parks that feed into high-voltage transmission networks.

• Advanced Rail Traction: For the main propulsion inverters in high-power locomotives and high-speed trains.

Why Partner with Us?

 Guaranteed Authenticity: We supply only factory-fresh, original ABB components with full traceability. Protect your multi-million dollar systems from counterfeit risks.

 Dedicated Technical Support: Our team has application knowledge in high-power systems. We provide expert pre-sales consultation to ensure compatibility.

Global Supply Chain Expertise: We handle international logistics, customs, and documentation seamlessly, ensuring your project stays on schedule.

Quality Assurance: Every module is supplied with its original packaging and documentation, backed by our comprehensive warranty.

Frequently Asked Questions (FAQ)

Q: What cooling method is required for this module?
A: The 5SHY3545L0020 is a press-pack module and must be clamped between two liquid-cooled heatsinks with a specific force (detailed in the datasheet) to ensure proper electrical contact and thermal performance.

Q: Can this module be used in parallel to increase current rating?
A: Yes, IGBTs can be paralleled. However, it requires careful design to ensure even current sharing through symmetric layout and gate driving. Consulting the application notes and our technical team is strongly recommended.

Q: Do you offer repair services for drives using this module?
A: We specialize in supplying new, genuine components. For drive repair and refurbishment services, we can recommend qualified partners.

Q: What is the typical lead time for large orders?
A: For large quantity orders, lead times can vary. Please use the "Get a Fast Quote" button for the most accurate scheduling and competitive pricing.

Order Your Genuine ABB 5SHY3545L0020

Equip your critical power conversion systems with the reliability and performance that only genuine ABB technology can provide.

Contact our specialists today for volume pricing, technical data, or to discuss your project needs.

Email:  sales5@xrjdcs.com  | Direct Line: +8618250705533

[I NEED A QUOTE FOR A LARGE PROJECT] [CONTACT A TECHNICAL EXPERT]
