Product Overview: Engineered for Ultra-High Power

The ABB 5SHY3545L0016 is a premium press-pack IGBT module from ABB's industry-leading HiPak series. Designed for the most demanding high-voltage applications, this module delivers exceptional performance with a 4500V blocking voltage and a 900A nominal current rating.

Its robust press-pack technology is critical for applications requiring series-stacking of modules to achieve very high voltage levels, superior thermal performance, and utmost reliability. This makes the 5SHY3545L0016 a cornerstone component in modern power transmission and heavy industrial systems.

Key Benefits & Features:

• Ultra-High Voltage Rating: 4500V collector-emitter voltage (Vces) for next-generation power electronics.

• Robust Press-Pack Design: Enables double-sided cooling for efficient heat dissipation and allows for safe failure modes, protecting entire systems.

• High Reliability & Long Lifetime: Built to withstand rigorous thermal cycling and mechanical stress, minimizing downtime in critical infrastructure.

• Low Stray Inductance: Optimized internal design for high switching efficiency and reduced electromagnetic interference (EMI).

Technical Specifications: ABB 5SHY3545L0016

Where is the 5SHY3545L0016 Used? (Applications)

This module is engineered for ultra-high-power conversion and is typically found in:

• HVDC Transmission Systems: The core component in voltage-sourced converter (VSC) stations for efficient long-distance power transmission.

• FACTS Devices: Used in Static Synchronous Compensators (STATCOMs) and Unified Power Flow Controllers (UPFCs) to stabilize and control power grids.

• High-Power Industrial Drives: For controlling very large motors in industries like mining, marine propulsion, and metal rolling.

• Renewable Energy Integration: In large-scale solar inverters and wind turbine converters connecting to high-voltage networks.

• Rail Traction: For main drive converters in high-speed trains and locomotives.

Why Source from Us?

 Genuine & Certified: We guarantee 100% authentic ABB components, sourced directly from authorized channels. Avoid counterfeit risks.

 Application Expertise: Our technical team understands high-power systems. We provide pre-sales support to ensure this module fits your application.

 Global Logistics: We ship worldwide with fully compliant documentation (CE, RoHS) to ensure smooth customs clearance.

 Secure Supply Chain: We understand the critical nature of your projects and offer reliable, traceable components.

Frequently Asked Questions (FAQ)

Q: Is the ABB 5SHY3545L0016 a direct replacement for the 5SHY3545L0014?
A: No. While from the same series, they have different voltage and current ratings (4500V/900A vs. 3300V/1200A). They are not directly interchangeable. Always confirm your system's requirements.

Q: What is the difference between a press-pack module and a standard module?
A: Press-pack modules are designed to be clamped between heatsinks for two-sided cooling, offer lower inductance, and have a failure mode that allows current to still pass through (short-circuit), which is safer for series-stacked applications in HVDC.

Q: Do you offer volume discounts?
A: Absolutely. Use the "Request Instant Quote" button for bulk order pricing, and our sales team will provide a competitive offer.

Q: Can you provide the module's wiring diagram?
A: The mechanical outline and terminal configuration are detailed in the datasheet. For specific application diagrams, please contact our technical team.

Ready to Order or Need More Info?

Power your most critical projects with the reliability of genuine ABB technology.

For technical questions, volume pricing, or expedited shipping options, speak to our experts today.
